**CONTACT US FOR MORE INFORMATION** 3 MONTHS WAIT TIME
MOTOR PERMANENT MAGNET SYNCHRONOUS 72V DC
CONTROLLER: APT72400
TOP SPEED: 75 MPH
DRIVE: ‘TWIST’ ELECTRONIC THROTTLE
PEAK POWER / VOLTAGE: PEAK 72V (DC) / 12Kw
RANGE: 30 to 75 MILES
BATTERY: LG LITHIUM BATTERY SYSTEM 72V 40Ah
SPEEDOMETER: LCD DIGITAL SPEEDO, GEAR
GEARING FRONT 13T, REAR 42T CNC / 4 GEAR SHIFT
CHARGER FAST AC180-240V, 50-60Hz, OUTPUT:92.4V, 20A
START START BUTTON WITH REMOTE ACTIVATION
WATERPROOF
ELECTRICS: IP67 (BODY IP54)
RIDE
CHASSIS MATERIAL
MACHINE WELDED STEEL
FRONT SUSPENSION FAST ACE USD 48mm Ø (PL&R ADJUSTABLE)
REAR SUSPENSION
FAST ACE 300mm 40mm (PL&R ADJ)
TYRES
F21” MXCST80/100 / R18” MXCST110/100
BRAKES
F DUAL PISTON / R SINGLE PISTON
FOOT BRAKE
YES
NET WEIGHT
95 KG
MAX RIDER WEIGHT
150 KG
WHEEL BASE
1350 mm
SEAT HEIGHT
880 mm
CLEARANCE
370 mm
HEAD ANGLE
25°
